Our PCB Manufacturing Process are highly geared towards prototype to mid volume production. We can offer Quick Turn Prototype PCB and Short Turn low to mid volume PCB Manufacturing. |
| |
| PCB MANUFACTURING CAPABILITY: |
|
 |
Rigid PCB, Flex PCB, Rig-Flex PCB |
|
Layer :
Single-sided up to 32 layers |
|
Material : FR4, CEM-1, Rogers,
Aluminium based, Leadfree compatible,
Polyimide - Polyester,
High-Tg, Halogen Free,
Taconic, Hi Frequency. |
|
Copper Thickness : 1Oz to 5Oz. (1Oz is standard) |
|
Board Thickness : 0.2mm to 6mm (1.6mm is standard) |
|
Surface Finishing : HASL, ENIG, ROHS HASL, OSP |
|
Soldermask : LPI – Green, Red, Blue, Black, White, Yellow (Green is standard) |
|
Silkscreen : White – 1sided or 2sided |
|
Custom Shape PCB |
|
Maximum Board Dimension : 23” x 35” |
|
Minimum Trace Width :3mil |
|
Minimum Separation : 3mil |
|
Minimum Via Size :0.05 mm micro via for Laser driller, Min. 0.15mm via for NC driller |
|
HDI pcb : 1+n+1, 2+n+2, |
|
Aspect ratio : 12:1 |
|
Impedance Tol. :
4 - 30 Layers up to 50Ω +/- 5 Ω; over 50 Ω +/- 5% |
|
Electrical Test : FREE Electrical Test for Single and Double Sided PCB |
|
Flying Probe Test : For multilayer PCB (optional) |
|
| |
| WHAT WE NEED TO PROCESS YOUR RoHSS: |
|
|
PCB Gerber Files or CAD Files in EAGLE CADSOFT, PROTEL DXP |
|
| |
Express Delivery: |
24 hour turnaround time on 2-4 layers PCB's,
2-4 day turn available up to ten layers;
over ten layers can be done in one week.
To shorten the cycle time of new product introduction,
lower costs and take initial market share,
Fastprint is tailor made to satisfy your needs.
|
| |
|
